Go Relational Database
Fully functional relational database written purely in Go.
Overview
Git repository is not public as it is UofA CSC 460 coursework.
Features
Core modules support disk access, query processing (filter, join, aggregate, insertion/deletion, projection, order-by, and limit), transactions handling, and concurrency control.
Integrates rigorous two-phase locking mechanism with page-level concurrency control (spinlocks, mutexes), deadlock detection for recovery, and no steal/force buffer management policy to handle disk/memory I/O.
No steal requires that dirty pages are not written to the disk before a transaction commits, and force requires that all changes made by a transaction once it commits are immediatey written to the disk. This combination simplifies database recovery protocol for crashes but leads to higher memory usage and slower performance as a trade-off.
Build
To build the database, make sure the Go toolchain is installed on your machine and then run
go buildin the root directory.The executable will be compiled as
mainwhich can be invoked with./main.
Usage
Typing \h will give a list of commands you can input; for example, \d lists the tables and their schemas. Tables are, by default, loaded from the file catalog.txt, but you can point to another catalog file. Note that each table in the catalog is stored in a file called <tablename>.dat, where tablename is the name of the table. From this terminal, you can run DROP, CREATE, INSERT, BEGIN, COMMIT/ROLLBACK, and SELECT statements. You can also load a CSV file into a table using the \l command.
The parser supports most of SQL with some limitations, including:
- No CTEs, window functions, recursive queries, or other SQL99 or later features (arbitrarily nested subqueries are fully supported)
- No OUTER joins (all joins are INNER)
- No USING clause for join predicates (you should write this to ON)
- No correlated subqueries
- No UPDATEs
When you first run the console, it will load a small test catalog containing two identical tables of people and ages. You can see the schemas of these tables using the \d command.
MBTA Example
As an example, you can load the famous MBTA dataset into GoDB format. You can download it from here. Note that all columns are either strings or ints; floats have been cast to ints in this database.
If you download and unzip this file in your top level lab, you can connect to over the console using the \c command:
1
2
3
4
5
6
7
8
9
> \c transitdb/transitdb.catalog
Loaded transitdb/transitdb.catalog
gated_station_entries (service_date string, time string, station_id string, line_id string, gated_entries int)
lines (line_id string, line_name string)
routes (route_id int, line_id string, first_station_id string, last_station_id string, direction int, direction_desc string, route_name string)
stations (station_id string, station_name string)
rail_ridership (season string, line_id string, direction int, time_period_id string, station_id string, total_ons int, total_offs int, number_service_days int, average_ons int, average_offs int, average_flow int)
station_orders (route_id int, station_id string, stop_order int, distance_from_last_station_miles int)
time_periods (time_period_id string, day_type string, time_period string, period_start_time string, period_end_time string)
Once it is loaded, you should be able to run a query. For example, to find the first and last station of each line, you can write:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
> SELECT line_name,
> direction_desc,
> s1.station_name AS first_station,
> s2.station_name AS last_station
> FROM routes
> JOIN lines ON lines.line_id = routes.line_id
> JOIN stations s1 ON first_station_id = s1.station_id
> JOIN stations s2 ON last_station_id = s2.station_id
> ORDER BY line_name ASC, direction_desc ASC, first_station ASC, last_station ASC;
line_name | direction_desc | first_station | last_station |
"Blue Line" | East | Bowdoin | Wonderland |
"Blue Line" | West | Wonderland | Bowdoin |
"Green Line" | East | "Boston College" | "Government Center" |
"Green Line" | East | "Cleveland Circle" | "Government Center" |
"Green Line" | East | "Heath Street" | Lechmere |
"Green Line" | East | Riverside | "North Station" |
"Green Line" | West | "Government Center" | "Boston College" |
"Green Line" | West | "Government Center" | "Cleveland Circle" |
"Green Line" | West | "North Station" | Riverside |
"Green Line" | West | Lechmere | "Heath Street" |
"Mattapan Trolley" | Inbound | Mattapan | Ashmont |
"Mattapan Trolley" | Outbound | Ashmont | Mattapan |
"Orange Line" | North | "Forest Hills" | "Oak Grove" |
"Orange Line" | South | "Oak Grove" | "Forest Hills" |
"Red Line" | North | Ashmont | Alewife |
"Red Line" | North | Braintree | Alewife |
"Red Line" | South | Alewife | Ashmont |
"Red Line" | South | Alewife | Braintree |
(18 results)
57.01075ms
You can also view the query plan generated for the query by appending the “EXPLAIN” keyword to a query, e.g.:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
> explain SELECT line_name,
> direction_desc,
> s1.station_name AS first_station,
> s2.station_name AS last_station
> FROM routes
> JOIN lines ON lines.line_id = routes.line_id
> JOIN stations s1 ON first_station_id = s1.station_id
> JOIN stations s2 ON last_station_id = s2.station_id
> ORDER BY line_name ASC, direction_desc ASC, first_station ASC, last_station ASC;
Order By line_name,direction_desc,first_station,last_station,
Project lines.line_name,routes.direction_desc,s1.station_name,s2.station_name, -> [line_name direction_desc first_station last_station]
Join, routes.last_station_id == s2.station_id
Join, routes.first_station_id == s1.station_id
Join, lines.line_id == routes.line_id
Heap Scan transitdb/lines.dat
Heap Scan transitdb/routes.dat
Heap Scan transitdb/stations.dat
Heap Scan transitdb/stations.dat
